Double Barbed Fittings
The Double Barbed Fittings manufacture!
Zhejiang Yijia Hydraulic Machinery Co., Ltd. is an industry and trade company for hardware production in China founded in 2013. The company focuses on brass fittings and customized precision parts.
Why choose us
Customized Solutions
We offer tailored hydraulic fittings and hoses designed to meet specific customer requirements. Our team works closely with clients to provide bespoke solutions that fit their unique applications and operational needs.
Our Certificate
Yijia Machinery has passed IATF 16949:2016 system certification,ISO 9001 & ISO 14001 system certification,DOT, AMECA product certification.
Rigorous Quality Control
We implement stringent quality control measures at every stage of production. Our adherence to ISO, BV, and TVU standards guarantees that each product meets the highest benchmarks for performance and safety.
Dedicated Customer Service
Our customer service team is committed to providing exceptional support and addressing any concerns promptly. We prioritize clear communication and proactive problem-solving to ensure a seamless experience for every client.
|
Part# |
Tube OD |
Tube ID |
PARKER |
|
1073-4-13 |
1/4*5/32 |
0.170*0.096 |
224-4-4-5/32 |
|
1073-6-13 |
3/8*5/32 |
0.250*0.096 |
224-6-6-5/32 |
|
1073-6-4 |
3/8*1/4 |
0.250*0.170 |
224-6-6-4 |
|
1073-8-4 |
1/2*1/4 |
0.375*0.170 |
224-8-8-4 |
|
1073-8-6 |
1/2*3/8 |
0.375*0.250 |
224-8-8-6 |
Design and installation
Design
Hose barb fittings are typically cylindrical, with one or multiple ridges (barbs). The barbs are designed to grip the inside of the hose, providing a secure and leak-resistant connection. The other end of the fitting is typically threaded. Hose barbs are generally used with soft side-type tubing, such as plastic or rubber tubing.
Hose clamps
Hose clamps are crucial in installing hose barb fittings, ensuring a secure and leak-free connection. They are designed to tighten around a hose, applying pressure and holding the hose onto the barb of the fitting. Using a hose clamp can greatly increase the pressure it can withstand, making it an essential component, especially in high-pressure applications.
Installation
To install a hose barb fitting, push the barbed end into the end of a hose. The barbs on the fitting make the connection tight and secure because they grip the inside of the hose. Use a clamp to secure the hose over the barb. This helps prevent the hose from coming off the fitting under pressure or with movement. The hose material fills the spaces between the barbs, which helps secure the fitting. To take the hose off the hose barb, cut the tubing with a knife so that it spreads away from the hose barbs. The fitting can usually be reused with a new hose.
Material of Double Barbed Fittings
Body Material: Standard materials include brass, steel, and nylon. Brass is common for its affordability and corrosion resistance for moderate applications. Steel offers higher strength for more demanding applications. Nylon is lightweight and corrosion resistant, but not suitable for high-pressure applications.
Sealing Material: If your barb fitting uses an O-ring or other seal, you can customize the material based on your fluid compatibility and temperature range.
|
OEM Parts |
|
|
1. Product Color |
Only send us your WeChat or WhatsApp No. we can match the colors here exactly. |
|
2. Product Logo/Sticke |
Send us the files in 'AI' or 'PDF' files. We can work out easily. |
|
3.Product Package |
Give us your packing design, we will pack it as your required. |
|
4. Product Specification |
Provide us exact date request,we can revised it professionally. |
Packaging & Shipping
Our factory
Yijia Hydraulic Machinery adopts full CNC machining, with a workshop area of 3600 square meters, equipped with 100 sets of full machine tools, 60 sets of semi-automatic CNC machines, and 5 sets of inspection equipment.We have an annual production capacity of 3 million sets of brass fittings and air brake hose assemblies.
